Fluxstir Motorless Magnetic Stirrer

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Product Description

This Fluxstir Motorless Magnetic Stirrer is aesthetically designed, compact and ultra flat stirring system. Ideally suited for many applications, the stirrer is very well designed to provide reliable performance for a host of mixing tasks. It provides flexible speeds as per different types of applications. Due to FRP housing the stirrer is completely corrosion resistant. The countdown timer along with the stirring speed in terms of RPM is displayed on the display of the Fluxstir Motorless Magnetic Stirrer during operation.

Features:

Easy to use
Adjustable speed
Excellent performance

Technical Specifications:

Model	FS 3
Number of Stations	1
Stirring Volume	50 ml-3 litres
Mains Input	240v. AC (-15 to + 10%) 50 Hz. (-15 to + 5%)
Fuse	1 No. 100 MA
Power consumption - Drive	6 watts
Power consumption - Heater	0
Speed Range (Standard)	100 - 900 R.P.M.
Speed Range (Optional)	50 - 150 R.P.M.
Speed Variation	Constant speed even if Viscosity changes or supply voltage vary within specified limits
Magnetic Stirring Paddle	9 mm dia x 35 mm long
Hot Plate Temperature	(Not Applicable)
Temperature Control	(Not Applicable)
Stirring Plate	130 mm dia.
Electrical Protection	Current Limit & Short Circuit
Housing - Base Plate	Aluminum
Housing - Top Plate	Stainless Steel
Hot Plate	(Not Applicable)
