Low Speed Research Centrifuge
Product Details:
X
Product Description
This Low Speed Research Centrifuge is widely used in auxiliary laboratories, educational & research institutions, bio technology, medical laboratories, hospitals, blood banks, pharmaceutical laboratories and agriculture industry for determination of moisture equivalent of soil. It is also suitable for determination of settlement of paints, pastes, cosmetics and food products. Checked on various parameters of performance and accuracy, this range of Low Speed Research Centrifuge is designed for varying centrifuge applications with higher volume tube capacities.
Features:
- Digital speed indicator
- Dynamic brake
- Imbalance detector
These centrifuges are designed for use of micro tubes - small capacity tubes, with the facility of inter-changeable rotor heads.
| Parameters | MP 800 |
| Control | Microprocessor with Variable Frequency Drive |
| Max. Speed | 10000 RPM |
| Max. RCF | 10500 x g |
| Choice of Tube/ Bottle Size | 1.5 ml to 250 ml |
| Max. Capacity | 1200 ml |
| Motor | Brushless Induction Motor |
| Display | Digital LCD |
| Program Features | User defined RPM/RCF, Acceleration, Deceleration & Timer with 25 Programs |
| Acceleration/ Deceleration | 12 - 510 Secs |
| Timer | 1 - 120 Min |
| Brake | Dynamic Brake |
| Safety | Sturdy Cabinet, Lid Lock, Imbalance Protection, Gas Spring |
| Security | Password Protection (Optional) |
| Choice of Rotor Heads (Angle & Swing Out) | 22 |
| Power Supply | 230V, 50 Hz |
Fix Angle Rotor Head:
| Model | Cap./ml | TC 8100 F | |
| RPM | RCF xg | ||
| TC 8102 | 12x25 | 7000 | 7100 |
| TC 8103 | 6x200 | 7000 | 7250 |
| TC 8104 | 8x100 | 7000 | 7100 |
| TC 8105 | 12x50 | 7000 | 7100 |
| TC 8106 | 36x15 | 7000 | 7100 |
| TC 4115 | 18x15 | 10000 | 10500 |
| TC 4111 | 24x1.5/2 | 10000 | 10500 |
| TC 8110 | 4x250 | 7000 | 7250 |
| TC 4118 | 24x3/4 Tubes | 10000 | 10400 |
| TC 4119 | 36x6/5/3 Tubes | 7000 | 7100 |
| TC 8101 J | 4(4x15) | 4500 | 2780 |
| TC 8101 G | 4(3x15) | 4500 | 2780 |
| TC 8101 I | 4(15x6) | 5050 | 5200 |
Buckets (carriers) suitable for use with TC 8101 Swing Out Rotor Head:
| Model | Cap./ml | Max.RPM | Max.RCF xg |
| TC 8101 A | 4x200 | 5200 | 5050 |
| TC 8101 B | 4x100 | 6100 | 6600 |
| TC 8101 C | 4x18 RIA (5ml) | 5200 | 4200 |
| TC 8101 V | 4x9 (2,3,4 &5 ml) | 5200 | 4200 |
| TC 8101 VL | 4x9 (6 ml) | 5200 | 4200 |
| TC 8101 D+E | 4x27 RIA (5ml) | 5200 | 4200 |
| TC 8107 | 2x1 MTP (Micro Titer Plate) | 3400 | 1700 |
| TC 8108 | 2x2 MTP (Micro Titer Plates) | 3400 | 1700 |
| TC 8109 | 4x250 | 5200 | 5050 |
Reduction Adaptors for use with Swing Out Rotor Carriers:
| TC 8111 | 100 ml in 200 ml carrier | TC 8118 | 3x15 ml in 100 ml carrier |
| TC 8112 | 50 ml in 200 ml carrier | TC 8116 | 25 ml in 100 ml carrier |
| TC 8114 | 7x15 ml in 200 ml carrier | TC 8121 | 1x50 ml in 250 ml carrier |
| TC 8113 | 3x30 ml in 200 ml carrier | TC 8122 | 3x25 ml in 250 ml carrier |
| TC 8117 | 13x5 ml in 200 ml carrier | TC 8123 | 5x15 ml in 250 ml carrier |
| TC 8115 | 50 ml in 100 ml carrier | TC 8124 | 13x5 ml in 250 ml carrier |
| TC 8125 | 7x3/4/5/6/7-10ml tubesin200mlcarrier Vac | ||
Model No: TC8100F
| Parameters | TC 8100 F |
| Control | Microprocessor with Variable Frequency Drive |
| Max. Speed | 10000 RPM |
| Max. RCF | 10500 x g |
| Choice of Tube/ Bottle Size | 1.5 ml to 250 ml |
| Max. Capacity | 1200 ml |
| Motor | Brushless Induction Motor |
| Display | Digital LCD |
| Program Features | User defined RPM/RCF, Acceleration, Deceleration & Timer with 25 Programs |
| Acceleration/ Deceleration | 12 - 510 Secs |
| Timer | 1 - 120 Min |
| Brake | Dynamic Brake |
| Safety | Sturdy Cabinet, Lid Lock, Imbalance Protection, Gas Spring |
| Security | Password Protection (Optional) |
| Choice of Rotor Heads (Angle & Swing Out) | 22 |
| Power Supply | 230V, 50 Hz |
Fix Angle Rotor Head:
| Model | Cap./ml | TC 8100 F | |
| RPM | RCF xg | ||
| TC 8102 | 12x25 | 7000 | 7100 |
| TC 8103 | 6x200 | 7000 | 7250 |
| TC 8104 | 8x100 | 7000 | 7100 |
| TC 8105 | 12x50 | 7000 | 7100 |
| TC 8106 | 36x15 | 7000 | 7100 |
| TC 4115 | 18x15 | 10000 | 10500 |
| TC 4111 | 24x1.5/2 | 10000 | 10500 |
| TC 8110 | 4x250 | 7000 | 7250 |
| TC 4118 | 24x3/4 Tubes | 10000 | 10400 |
| TC 4119 | 36x6/5/3 Tubes | 7000 | 7100 |
| TC 8101 J | 4(4x15) | 4500 | 2780 |
| TC 8101 G | 4(3x15) | 4500 | 2780 |
| TC 8101 I | 4(15x6) | 5050 | 5200 |
Buckets (carriers) suitable for use with TC 8101 Swing Out Rotor Head:
| Model | Cap./ml | Max.RPM | Max.RCF xg |
| TC 8101 A | 4x200 | 5200 | 5050 |
| TC 8101 B | 4x100 | 6100 | 6600 |
| TC 8101 C | 4x18 RIA (5ml) | 5200 | 4200 |
| TC 8101 V | 4x9 (2,3,4 &5 ml) | 5200 | 4200 |
| TC 8101 VL | 4x9 (6 ml) | 5200 | 4200 |
| TC 8101 D+E | 4x27 RIA (5ml) | 5200 | 4200 |
| TC 8107 | 2x1 MTP (Micro Titer Plate) | 3400 | 1700 |
| TC 8108 | 2x2 MTP (Micro Titer Plates) | 3400 | 1700 |
| TC 8109 | 4x250 | 5200 | 5050 |
Reduction Adaptors for use with Swing Out Rotor Carriers:
| TC 8111 | 100 ml in 200 ml carrier | TC 8118 | 3x15 ml in 100 ml carrier |
| TC 8112 | 50 ml in 200 ml carrier | TC 8116 | 25 ml in 100 ml carrier |
| TC 8114 | 7x15 ml in 200 ml carrier | TC 8121 | 1x50 ml in 250 ml carrier |
| TC 8113 | 3x30 ml in 200 ml carrier | TC 8122 | 3x25 ml in 250 ml carrier |
| TC 8117 | 13x5 ml in 200 ml carrier | TC 8123 | 5x15 ml in 250 ml carrier |
| TC 8115 | 50 ml in 100 ml carrier | TC 8124 | 13x5 ml in 250 ml carrier |
| TC 8125 | 7 x 3/4/5/6/7 - 10ml tubes in 200ml carrier | ||
Model No: TC 8100 D
| Parameters | TC 8100 D |
| Control | Microprocessor |
| Max. Speed | 7000 RPM |
| Max. RCF | 7250 x g |
| Choice of Tube/Bottle Size | 3 ml to 250 ml |
| Max. Capacity | 1200 ml |
| Motor | Universal Motor |
| Display | Digital LCD with Set & Working Parameters |
| Program Features | Last Used Program Memory |
| Acceleration/ Deceleration | 30 - 300 Secs |
| Timer | 1 - 99 Min |
| Brake | Electronic Brake |
| Safety | Sturdy Cabinet, Lid Lock, Imbalance Protection, Gas Spring |
| Choice of Rotor Heads (Angle & Swing Out) | 20 |
| Power Supply | 230V, 50 Hz |
Fix Angle Rotor Head:
| Model | Cap./ml | TC 8100 D | |
| RPM | RCF xg | ||
| TC 8102 | 12x25 | 7000 | 7100 |
| TC 8103 | 6x200 | 7000 | 7250 |
| TC 8104 | 8x100 | 7000 | 7100 |
| TC 8105 | 12x50 | 7000 | 7100 |
| TC 8106 | 36x15 | 7000 | 7100 |
| TC 8110 | 4x250 | 7000 | 7250 |
| TC 4118 | 24x3/4 Tubes | 7000 | 5000 |
| TC 4119 | 36x6/5/3 Tubes | 7000 | 7100 |
Buckets (carriers) suitable for use with TC 8101 Swing Out Rotor Head:
| Model | Cap./ml | Max.RPM | Max.RCF xg |
| TC 8101 A | 4x200 | 5200 | 5050 |
| TC 8101 B | 4x100 | 6100 | 6600 |
| TC 8101 C | 4x18 RIA(5ml) | 5200 | 4200 |
| TC 8101 V | 4x9 (2,3,4 &5 ml) | 5200 | 4200 |
| TC 8101 VL | 4x9 (6 ml) | 5200 | 4200 |
| TC 8101 D+E | 4x27 RIA(5ml) | 5200 | 4200 |
| TC 8107 | 2x1 MTP (Micro Titer Plate) | 3400 | 1700 |
| TC 8108 | 2x2 MTP (Micro Titer Plates) | 3400 | 1700 |
| TC 8109 | 4x250 | 5200 | 5050 |
| TC 8101 J | 4(4x15) | 4500 | 2780 |
| TC 8101 G | 4(3x15) | 4500 | 2780 |
| TC 8101 I | 4(15x6) | 5200 | 5050 |
Reduction Adaptors for use with Swing Out Rotor Carriers:
| TC 8111 | 100 ml in 200 ml carrier | TC 8118 | 3x15 ml in 100 ml carrier |
| TC 8112 | 50 ml in 200 ml carrier | TC 8116 | 25 ml in 100 ml carrier |
| TC 8114 | 7x15 ml in 200 ml carrier | TC 8121 | 1x50 ml in 250 ml carrier |
| TC 8113 | 3x30 ml in 200 ml carrier | TC 8122 | 3x25 ml in 250 ml carrier |
| TC 8117 | 13x5 ml in 200 ml carrier | TC 8123 | 5x15 ml in 250 ml carrier |
| TC 8115 | 50 ml in 100 ml carrier | TC 8124 | 13x5 ml in 200 ml carrier |
| TC 8125 | 7 x 3/4/5/6/7 - 10ml tubes in 200ml carrier. | ||
This model is also offered with CE Mark on customer request
