Vertical Deep Freezer

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Product Description

Vertical Deep Freezer is double walled cooled unit, in which the outer body is designed of thick material and the inner chamber is made of heavy gauge sheet. It is incorporated with PUF insulation and high pressure injection machine to protect the equipments from temperature fluctuations and environmental friendly CFC free refrigerants as coolants for increased energy efficiency. Besides, this Vertical Deep Freezer has a sturdy construction and key board lock with an audio alarm.

Features:

Minimal maintenance
Easy to use
Space saving design

Technical Specifications:

MODEL NO.	EDF-100	EDF-200	EDF-300	EDF-400	EDF-500	EDF-600
Volume	100 Ltrs	200 Ltrs	300 Ltrs	400 Ltrs	500 Ltrs	600 Ltrs
Chamber Dimension	450x450x500	500x450x900	500x550x1100	550x600x1215	600x600x1400	600x700x1440
External Dimension	610x700x1000	660x700x1400	660x800x1600	710x850x1725	760x850x1400	760x920x1950
No. of Stainless Steel Trays (Basket)	2	3	4	4	5	6
Temperature	-20Â°C	-20Â°C	-20Â°C	-20Â°C	-20Â°C	-20Â°C
Input Voltage	230VAC 50Hz	230VAC 50Hz	230VAC 50Hz	230VAC 50Hz	230VAC 50Hz	230VAC 50Hz

*GMP Model: Inside stainless steel 304, 0.8mm thick and outside stainless steel 304, 1.00mm thick.

Standard Model: Inside Stainless Steel 304, 0.8mm thick and outside 1.00mm mild Steel powder coated.

Operational Accessories:

8.14 temperature data scanner with sensors, printer interface data management, drive data retrieval facility.

Mobile alert via GSM in case system fails.

Calibration:

The equipment calibrated with the help of master calibrator, which is certified for its accuracy by Electronics Regional Test Laboratory (ERTL - Mumbai).
